AquaCal TropiCal T115 112,000 BTU Heat Pump

• Optimum heat output in a small footprint
• Large surface and corrosion-resistant evaporator
• Vinyl coated fan grill
• Microprocessor-controlled automatic defrost allows operation down to the mid to lower 40s
• High-performance titanium heat exchanger (patented ThermoLink heat exchanger in the T115 model)
• Built-in drain pan for condensate management
• Impact-resistant, rust and fade-proof cabinet
• Quieter than conventional heat pumps
• Smart microprocessor control with water temperature setpoint dial (60°–104°F)
• Weather-protected and lockable flip-out control panel
• Compatible with most external controllers
• Smartphone control available with PoolSync app (WiFi Controller sold separately)
• Rated in accordance with AHRI Standard 1160
• AHRI Certified® for performance and quality assurance

Now you can control your heat pump right through your smartphone. Adjust your temperature setting using the PoolSync app. *Requires PoolSync WiFi Controller (sold separately)

Side-by-Side Performance Comparison

BTU Output:

• 80/80/80: T55 – 50,000 | T75 – 70,000 | T115 – 112,000
• 80/80/63: T55 – 47,500 | T75 – 67,000 | T115 – 106,000
• 80/50/63: T55 – 30,000 | T75 – 46,000 | T115 – 74,000

Coefficient of Performance (C.O.P.):

• 80/80/80: T55 – 5.8 | T75 – 5.5 | T115 – 5.7
• 80/80/63: T55 – 5.5 | T75 – 5.3 | T115 – 5.4
• 80/50/63: All models – 4.0

Refrigerant:

• R410A for all models

Heat Exchanger:

• T55 & T75: Tube-in-Tube
• T115: ThermoLink (patented)

Electrical:

• KW Input: T55 – 2.5 | T75 – 3.7 | T115 – 5.8
• Voltage/Hz/Phase: 208–230V / 60Hz / 1-phase
• Min Circuit Amps: T55 – 19.7 | T75 – 25.8 | T115 – 40
• Max Fuse Size: T55 – 30 | T75 – 45 | T115 – 60

Water Flow (gpm):

• T55 & T75 – 20 to 45 gpm
• T115 – 30 to 70 gpm

Physical Specs:

• Weight (lbs): T55 – 230 | T75 – 265 | T115 – 300
• Shipping Weight (lbs): T55 – 240 | T75 – 275 | T115 – 310
• Dimensions (LxWxH): T55 – 36″x24″x27″ | T75 – 36″x24″x31″ | T115 – 37″x28″x37″
• Noise Level: 65 dB

50 Hz Units

Efficiency:

• KW Output: T35 – 10.26 | T55 – 12.02 | T75 – 16.85
• BTU Output: T35 – 35,000 | T55 – 41,000 | T75 – 57,500
• C.O.P.: T35 – 6.5 | T55 – 6.6 | T75 – 6.0
• KW Input: T35 – 1.5 | T55 – 1.8 | T75 – 2.8

Electrical (50 Hz Models):

• Voltage/Hz/Phase: 200–240V or 380–420V / 50Hz / 1 or 3-phase depending on variant
• Min Circuit Amps: T35 – 12.2 | T55 (1ph – 15.6, 3ph – 6.9) | T75 (1ph – 19.5, 3ph – 9.1)
• Max Fuse Size: T35 – 20 | T55 (1ph – 25, 3ph – 10) | T75 (1ph – 30, 3ph – 15)

Water Flow:

• Min/Max: 20–45 gpm or 4.5–10.2 m³/h

Dimensions:

• Weight (kg): T35 – 109 | T55 – 109 | T75 – 125
• Dimensions (cm): T35 & T55 – 92x61x69 | T75 – 92x61x79
• Sound Level: 65 dB at 10 ft
